Products & Equipment

Our Fleet: Owned, Maintained and Site-Ready.

Our equipment spans civil construction plant, specialised heavy lift systems and underground machinery, all owned, maintained and site-passed for rapid deployment.

350+ Pieces of Owned, Site-Certified Equipment, Ready to Move.

When your project needs equipment on site fast, the last thing you want is a contractor waiting on hire approvals. Every piece of our fleet is already site-certified and maintained by our team.

Civil and Earthmoving Plant

Excavators, loaders and dump trucks across a range of configurations. We own earthmoving fleet for surface civil and infrastructure scopes.

A large yellow bulldozer works on a dirt slope inside a deep open-pit mine with terraced walls under a bright blue sky.

Specialised Lifting Equipment

Strand jacks, chain jacks and heavy lift systems designed, owned and operated by our team for complex lifts across mining, construction and marine projects.

Large red industrial machine with coiled black cables sits inside a warehouse near an open door. Metal railings, a ladder, and various equipment are visible in the background under a metal roof.

Winches and Winders

A substantial inventory of purpose-built winches and winders for underground and surface applications, manufactured and maintained in-house.

Large industrial winch with a wound steel cable on a blue base, placed indoors on a concrete floor, with a beige curtain backdrop and visible control cables attached.

Products & Equipment

Our Products

LifePoint Fall Arrest Anchor System

LifePoint was developed by our in-house engineering team in response to a specific site challenge, and it’s available to operators who need a reliable, compliant anchor solution for high-risk working environments.

A proprietary, engineered anchor point system designed for use in mining and construction environments where standard fall arrest solutions are inadequate.

Engineered, not adapted

LifePoint was purpose-designed for the specific demands of underground and surface mining environments, not retrofitted from a standard product.

Compliance built in

Designed to meet relevant Australian standards for fall arrest anchorage. Detailed compliance documentation available on request.

Backed by MCA's engineering team

If your application is non-standard, our engineers can advise on the right configuration. You’re not buying off a shelf, you’re engaging an engineering business.

Talk to us today

Available for hire or sale along with a range of other sizes and capabilities.
Contact us.

A close-up of an orange metal safety ring attached to a threaded pipe fitting mounted on a wall with a mosaic pattern.
Large industrial winch with coiled steel cable on a blue metal frame labeled “MCA-HT-25-W,” inside a factory with grey walls and yellow crane rails above. Safety tags and company branding are visible.

25000kg Winch

The MCA 25000kg Winch is the optimal solution in shaft maintenance and egress systems.

Underground mining depends critically on the capability, reliability and safety of the hoisting equipment. MCA Engineering have designed and manufactured a 25 Tonne Winch that assures the highest level of safety coupled with maximum performance.

MCA’s 25000kg Winch was designed to meet a client’s requirement of having a shaft maintenance winch as well as a unit that could also provide Emergency Egress. Therefore the winch’s main purpose is shaft maintenance including rope changes, bridal and skip changes with the option of man riding.

The winch drum is driven by a variable displacement hydraulic motor via a reduction gearbox mechanism. In turn the hydraulic motor is driven by either a diesel or electric motor. This solution gives huge torque with exceptional control.

With a customer focused design, the 25 Tonne winch is your optimal solution in shaft maintenance and egress systems.

Talk to us today

Available for hire or sale along with a range of other sizes and capabilities.
Contact us.

Chain Jack System

Mooring | Lifting | Ship lift

MCA Engineering’s chain jack assembly has been developed with a highly customer focused approach and the ability to provide high value solutions for a diverse range of customer requirements. The chain jack system represents one of the safest and most efficient ways to lift or lower heavy loads in confined spaces.

The initial design of the chain jacking system was to lower steel linings into an underground ore pass delivery system. For this application the chain jacking system was used to both lower and raise the ore bin linings in a safe, precise and reliable manner.

However the list of applications for this robust, easy to install equipment is extensive. Whether you need to lift 10 Tonne or 1000 Tonne, MCA Engineering can design and manufacture a solution to meet your heavy lifting requirements.

Specifications

Stroke

1000mm

Chain

32mm Grade 80

SWL

31.500 tonne per Jack

Lowering

300mm per/min

Lift

300mm per/min

Weight

885kg

Pressure Main Jack

2,000 PSI

Pressure Load Levelling Cylinders

10,000 PSI

Talk to us today

Available for hire or sale along with a range of other sizes and capabilities.
Contact us.

Industrial equipment arranged in a circular formation with yellow railings, safety barriers, chains, and a metal container with green straps in a facility with a protective wall covering.
A large industrial winch with a steel cable is mounted on a blue base on a concrete floor in a workshop. Nearby are cables, machinery, and storage shelves.

Air Winch

Designed to Australian Standards, the Air Winch with 300m rope capacity is the optimal solution for construction, mining and marine applications, built specifically for performance and reliability.

Underground mining depends critically on the capability, reliability and safety of the hoisting equipment. Designed and manufactured by MCA in Australia in accordance with Australian Standards, the Air Winch’s winch drum is driven by an air motor via a 90 degree reduction gear box to a planetary drum mounted winch drive that is powered by a 10kW air motor.

The Air Winch is designed to be operated in lifting and lowering or pulling of materials only, and is not to be used for man riding.

Specifications

Drum

Rope

Winder

Diameter

406mm

16mm (max)

Width/Length

650mm

300m (max)

Number of Layers

n/a

5

Brake Torque

n/a

397Nm Integral

Speed

n/a

10 m/Min @ min 160 L/SP

Air Requirement

n/a

160L per min

Motor Power

n/a

10kW

Talk to us today

Available for hire or sale along with a range of other sizes and capabilities.
Contact us.

Strand Jack System

Strand jacks are powerful linear winch systems designed for controlled pulling of heavy loads from above. They are ideal for heavy construction projects such as bridges, ports, and large-scale plant maintenance.

Unlike traditional jacks that push a load upwards, strand jacks utilize a unique pulling mechanism. A bundle of high-strength steel strands is gripped by two clamps within the system. One clamp is fixed in place, while the other is connected to a powerful hydraulic cylinder. Through a precise sequence of gripping, releasing, and hydraulic movement, strand jacks progressively lift the load with exceptional control.

Talk to us today

Available for hire or sale along with a range of other sizes and capabilities.
Contact us.

Large red industrial machine with coiled black cables sits inside a warehouse near an open door. Metal railings, a ladder, and various equipment are visible in the background under a metal roof.
Two large industrial winches are housed under a white canopy, surrounded by metal fencing, at a construction site with machinery, containers, and construction materials visible in the background.

Construction Headframe and Winding System

MCA’s Construction Headframe and Winding System presents the latest innovation in rope winding equipment for mining and construction industries. Providing customisable equipment with superior capabilities, MCA caters to a project’s specific needs and demands.

24m Headframe

The 24000 Class Construction Headframe has been especially designed to perform a large variety of shaft work. The system incorporates a 15m x 15m square layout of the support footings, allowing a significant span to avoid existing or future infrastructure required around the shaft collar. The steel foundation option allows for a rapid set up and demobilisation.

1200 Class Winder

The 1200 Class Winder is the latest innovation in rope winding equipment for the mining, construction and marine industry. Designed and manufactured in accordance with relevant Australian Standards and Guidelines, the 1200 Class Winder’s compact design provides a small footprint for installation, while its integrated hydraulic drive offers exceptional performance.

Market leading, innovative technology within the design allows for unprecedented fine control of large rope loads, increasing your lifting capacity and control, while meeting the highest safety requirements.

The 1200 Class Winder is manufactured in Australia, in partnership with highly reputable local supply partners, ensuring life-long reliability.

Mechanical Design

  • Grooved shells RHLL to 36mm interchangeable rope sizes
  • Bolt on brake discs (2000mm diameter)
  • Spring apply hydraulic release brake callipers (200% capacity each path)
  • Dual redundant brake return poppet valve system
  • Planetary drive reducing foot print increased torque and control
  • Integrated shaft to winder communication MDG 2005

1200 Class Cage Winder

Safe access throughout the depth of the shaft is available via the 1200 Class Cage Winder. Together with the Headframe and Stage, it operates as a fully integrated system, preventing any risk of falls. Gates on the Headframe and Stage are interlocked to ensure access is only available when the cage is docked at the relevant location and the system is in a “ready to operate” condition. This also applies to the doors on the man riding conveyance, which will only allow operation when in a safe location. The 1200 Class Cage Winder incorporates a customisable shell design that allows for different rope sizes to be interchanged as required for the project.

1200 Class Stage Winder

Shaft work is completed via the utilisation of the stage; a movable work platform operated via the 1200 Class Stage Winder. Stage construction is fully customisable to suit the conditions and requirements of any job, with alterations including the number of and spacing between working decks, and stage diameter. Stage designs also incorporate equipment allowing highly efficient and safe projects, such as a hydraulic actuated davit arm crane, which can be used to position services against the shaft wall during installation.

Talk to us today

Available for hire or sale along with a range of other sizes and capabilities.
Contact us.
